AGFRC A66FHLW Low Profile Steel Gears Brushless Digital Servo Motor
stars, based on 0 reviews
Estimated Standard shipping time is about 4 ~ 8 days
For the inventory goods, the package will be dispatched within 3 working days
Product Tag:
Low ProfileAGFRC A66FHLW CNC Case Steel Gears 60KG Super Torque 0.100Sec 4-Pole Brushless Waterproof Servo For RC Boats/Cars
AGFRC A66FHLW Digital 4-Pole Brushless Servo of the new generation with newly developed and the top shape design, housing fully made of CNC aluminum, extremely strong steel gears, and metal double ball bearings. Due to the upgraded 4-Pole brushless motor, this high-powered low-profile servo outputs a whopping 60 kg-cm of torque and 0.100Sec at 8.4V in this short body. The magnetic sensor waterproof IP67 function is added, so you are able to have a free run in water and keep on going for up to 30 minutes. Suitable for applications that require large torque output and need to be waterproof.
Main Features
• Metal Ball Bearings
• High Smooth Steel Gears
• Full Aluminium Heat Sink Case
• Magnetic Sensor Waterproof IP67
• Good Quality Brushless Motor
• Super Torque Digital Low Profile Servo
• Fully Waterproof IP67
• Suitable for most RC Vehicles, cars, Boats, Aircraft, and industrial which require a large torque servo.
Specifications
Operating Voltage
4.8V - 8.4V
Temperature Range
-15°C - +70°C
Refresh Rate
1520 µS / 333Hz
Travel Angle
180 ± 10°
Programmable
Yes
Case Material
Aluminum
Gear Material
Strength Steel
Position Sensor
Magnet Angle Sensor
Motor Type
4-Pole Brushless
Bearing
2BB
Direction
CCW
Horn Gear Spline
25T-ɸ5.92 mm
Wire
TYU 300mm / 22AWG
Wire Color
Dimensions
40.8*20.2*29.5mm
Weight
66g
Operating Speed
0.145 sec/60° @4.8V
0.132 sec/60° @6.0V
0.115 sec/60° @7.4V
0.100 sec/60° @8.4V
Stall Torque
41 kg·cm (569 oz·in) @4.8V
46 kg·cm (639 oz·in) @6.0V
53 kg·cm (736 oz·in) @7.4V
60 kg·cm (834 oz·in) @8.4V
Package Includes
Servo
1 x A66FHLW Servo
Metal Horn
1 x 25T Metal Horn
Plastic Horn
2 x 25T Plastic Horn
Screw
4 x Mounting Screw
1 x Servo Horn Screw
Other Accessories
4 x Rubber Pad
4 x Copper Sleeve
Download
• Perhaps you will need a spec datasheet or other related documents of the products. If there is a download button, it means you can simply click to download. We will continuously update the latest files for each product.
• If you do not find the file you want, please feel free to contact shopping@agfrc.com directly.
Download
