AGFRC
0.17Sec HV Digital Programmable High Speed Servo(B53DHN)
AGFRC 20kg HV Programmable High Torque Aluminum Middle Case 0.17Sec High Speed Titanium Gear Digital Standard Budget Servo for 1/10 RC Models (B53DHN)
AGFRC B53DHN affordable programmable digital DC servo not only inherited the beautiful yellow "coat" of B53DHS but also inherited its advantages.
It has a faster speed of 0.17sec and 20KG torque, Dust and splash housing and super silky double bearings. Programmable digital circuits provide you with more high-quality choices. It ideal for 1/10 RC Cars, Airplanes, Boats, Drone, Educational Robot, Robotic arm etc. B53DHN not only has an Affordable price, but also meets the functional needs of most customers. Looking forward to this new partner can surprise you~
Feature
Programmable Digital DC Servo
Medium Aluminum Case
2S Lipo Wide Voltage Capable
Environmentally Friendly Materials
Super Silky Double Ball Bearing
High Strength Titanium Gear
Dust and Splash Resistant
Ideal for 1/10 RC Cars, Airplanes, Boats, Educational Robot, Robotic Arm etc.
Stall Torque
- 13.0 kg-cm (236 oz-in) @ 4.8V
- 15.0 kg-cm (264 oz-in) @ 6.0V
- 18.0 kg-cm (299 oz-in) @ 7.4V
- 20.0 kg-cm (334 oz-in) @ 8.4V
- Operating Speed
- 0.23sec/60° @ 4.8V
- 0.21sec/60° @ 6.0V
- 0.20sec/60° @ 7.4V
- 0.17sec/60° @ 8.4V
Package Included
Item 1
- 1 x B53DHN Programmable Digital Servo
- 1 x Assessory Kit
Item 2
- 1 x B53DHN Programmable Digital Servo
- 1 x 25T Metal servo Horn
- 1 x Assessory Kit
Item 3
- 1 x B53DHN Programmable Digital Servo
- 1 x AGF-SPV3 Servo Programmer
- 1 x 25T Metal servo Horn
- 1 x Assessory Kit
- Note:1. Item 1 does not include the AGF-SPV3 servo programmer.
- 2. This product price does not include EU VAT.
- Brand:
- AGFRC
- Iterm Name:
- A53DHN
- Signal Mode:
- Digital
- Control System:
- Pulse width modulation control
- Refresh Rate:
- 333Hz
- Neutral Position:
- 1520uS
- Dead band:
- 4 uSec
- Operating Voltage:
- 4.8V~8.4V
- Operating Travel:
- 180°±10°
- Mechanical Angle:
- 220°
- Signal Range:
- 500 to 2500 uSec
- Angle Sensor:
- Potentiometer
- Temperature:
- -15C°~ +70C°
- Motor Type:
- DC
- Motor Drive:
- FET Drive
- Programmable:
- Yes
- Horn Gear Spline:
- 25T-φ5.92mm
- Bearing:
- Double Ball Bearings
- Bearing Material:
- Metal
- Gear Material:
- Titanium
- Case Material:
- AL+Plastic
- Certification:
- CE,FCC,RoHs
- Product Size:
- 40*20*42.3mm(1.57*0.79*1.67in)
- Wire Guage:
- JR 360mm / 22AWG
- Net Weight:
- 63g(2.22oz)
