AGFRC
SA86BVMW 66KG High Torque 3S Lipo Waterproof Programmable Servo
With sufficient stock, packages will be shipped within 2 working days.
Insufficient stock, we will inform you as soon as the lead time is confirmed.
The package is expected to be delivered within 4 - 9 days after shipment.
AGFRC 66KG High Torque 3S Lipo Waterproof Programmable Servo (SA86BVMW)
As 2s lipo application cannot meet more and more people's usage, this 12V Series Smart Servo especially designed for higher voltage application, such as R/C Crawler Cars, Airplanes, Boats, Robots or Industrial/Medical applications.
Main Features
• Simplify - 3S Lipo high voltage application, available to connect with battery directly.
• Smooth - Three ball bearings to make it more powerful and smoother.
• Powerful - Extra strong patent steel gears and upgrade structure.
• Reliable - High quality brushless motor for longer servo life.
• Waterproof - High accuracy magnetic position sensor, allow to be used in humid or rainy situation.
• Precision - High precision CNC aluminum machined housing.
• Ideal for on-road, off-road, Truck, Boat, Airplane, Helicopter etc.
Specifications
Operating Voltage
4.8V - 8.4V
Temperature Range
-15°C - +70°C
Refresh Rate
1520 µS / 333Hz
Travel Angle
180 ± 10°
Programmable
Yes
Case Material
Aluminum
Gear Material
Strength Steel
Position Sensor
Magnet Angle Sensor
Motor Type
Brushless
Bearing
3BB
Direction
CCW
Horn Gear Spline
25T-ɸ5.92 mm
Wire
TYU 300mm / 22AWG
Wire Color
Dimensions
40*20*41.5mm
Weight
90.5g
Operating Speed
0.155 sec/60° @9.9V
0.145 sec/60° @10.8V
0.125 sec/60° @12.0V
0.120 sec/60° @12.6V
0.105 sec/60° @14.4V
Stall Torque
40 kg·cm (556 oz·in) @9.9V
46 kg·cm (639 oz·in) @10.8V
57 kg·cm (792 oz·in) @12.0V
60 kg·cm (834 oz·in) @12.6V
66 kg·cm (917 oz·in) @14.4V
Package Includes
Servo
1 x SA86BVMW Servo
Metal Horn
1 x 25T Metal Horn
Plastic Horn
2 x 25T Plastic Horn
Screw
4 x Mounting Screw
3 x Servo Horn Screw
Other Accessories
4 x Rubber Pad
4 x Copper Sleeve
Download
• Perhaps you will need a spec datasheet or other related documents of the products. If there is a download button, it means you can simply click to download. We will continuously update the latest files for each product.
• If you do not find the file you want, please feel free to contact shopping@agfrc.com directly.
Download
