SA75CVSW V2 0.090Sec High Speed 45Kg High Torque Waterproof Programmable Coreless Smart Winch Servo For 1/8 Builds
With sufficient stock, packages will be shipped within 2 working days.
Insufficient stock, we will inform you as soon as the lead time is confirmed.
The package is expected to be delivered within 4 - 9 days after shipment.
AGFRC SA75CVSW HV 0.090Sec 45Kg High Torque Programmable Heightened Waterproof Standard Digital Servo
➤ As 2s Lipo application cannot meet more and more people's usage, this 3s Lipo 12V Series Smart Servo is especially designed for higher voltage applications, such as R/C Crawler Cars, Airplanes, Boats, Robots, or Industrial/Medical applications. The highlight of this smart servo is available to upgrade the firmware via a USB programmer for different usage as required.
MAIN FEATURES
➤ 3S Lipo.
➤ Dual ball bearings.
➤ Extra-strong patent steel gears and upgrade structure.
➤ High-quality coreless motor for higher speed.
➤ High accuracy magnetic position sensor allow to be used in humid or rainy situations.
SPECIFICATIONS
Operating Voltage
10V - 13V
Temperature Range
-15°C - +70°C
Refresh Rate
1520 µS / 333Hz
Travel Angle
180 ± 10°
Programmable
Yes
Case Material
Aluminum
Gear Material
Strength Steel
Sensor Type
Magnetic Sensor
Motor Type
Brushless
Bearing
2BB
Direction
CCW
Horn Gear Spline
25T-ɸ5.92 mm
Wire
TYU+JST 300mm / 22AWG
Wire Color
Dimensions
40*20*41.5mm
Weight
82g
Operating Speed
0.105 sec/60° @11.1V
0.093 sec/60° @12.0V
0.090 sec/60° @12.6V
Stall Torque
39 kg·cm (542 oz·in) @11.1V
42 kg·cm (583 oz·in) @12.0V
45 kg·cm (625 oz·in) @12.6V
PACKAGE INCLUDES
➤ 1 x SA75CVSW V2 Servo
➤ 1 x 25T Metal Horn
➤ 3 x 25T Plastic Horn
➤ 4 x M3 * 12mm Screw
➤ 1 x M3 * 8mm Screw
➤ 2 x M2 * 8mm Screw
➤ 4 x Rubber Pad
➤ 4 x Copper Sleeve
➤ 1 x AGFRC Logo Sticker
➤ 1 x Silicon JST (Male) to XH2.5 4-Pin (Female) Adapter Cable, 20AWG, 10cm
➤ Perhaps you will need a spec datasheet or other related documents of the products. If there is a download button, it means you can simply click to download. We will continuously update the latest files for each product.
➤ If you do not find the file you want, please feel free to contact shopping@agfrc.com directly.
By
Steve Staffs
2020/11/9 17:38:03
Awesome servo, really strong, I can use it on 3S Lipo battery directly without ESC, it also can be programmed as a winch servo, very impressive.
1
By
Jake Savage
2020/10/13 10:58:12
Five Stars, Good delivery working very well
1
1
By
Harry
2020/9/10 4:45:08
Super Fast Delivery to Switzerland! (3days!! Only)Im very impressed of the servo, cant proof if it really delivers the specified torque but its more than enough. So actually I reduced the torque with the programming module. The servo was delivered with reduced torque from factory settings, so I do recommend to have the programming adapter. Settings are very easy to understand. Now I hope the servo will last long. and Im Just considering buying another one :-) P.s, cant upload pictures
By
Ryan
2020/9/1 19:50:13
Great servo, very powerful and smooth. This is my go to servo for all my RC’s.
