ARFRC 36KG IP67 Waterproof Upgrade Structure High Torque Programmable Digital 0.071Sec High Speed Brushless Steering Servo for 1:10 Scale Monster Truck, Buggy,Crawler(A80BHSW V2)

The A80BHSW V2 is fully upgrade inside structure to make it much more stronger and reliable for 1/10 scale models. Updated with latest designed laser engraving pattern for a new look. Enhance pin shaft and upgrade gear material, smooth three ball bearings and high-quality long-life brushless motor which make it  trustworthy when you climping in the hill or throught the rock.


High voltage compatibility of up to 8.4V, not only with fast response speed, but also has a good heat dissipation effect. Effectively solve the problem of heating of the servo system under long-time work. High accuracy digital magnetic position encoding, which feature waterproof function up to IP67 grade. It can be used even in the environment of muddy roads, streams, breeze and drizzle. Even if it snows, you can take it and make a snowman with your model. If you prefer custom parameter programming, it can also meet your requirements. AGFRC always listens to the requirements and suggestions of the public and brings more high-quality products to everyone.


Feature

High Performance Digital Standard Servo

Fully Aluminum Housing and Structure

Enhanced Steel Gears and Pin Shaft

High Strength Three Ball Bearings

High Efficiency Bruhless Motor

Built-in Magnetic Sensor

Fully Waterproof IP67 Rated

USB Programmable Circuit

Ideal for 1/10, On Road, TRX6, Arrma Mojave EXB-Roller Desert Truck, Off Road, Monster Truck, Airplane, Helicopter, Robot and Engine etc.


Stall Torque

  • 23 kg-cm (319 oz-in) @ 4.8V
  • 28 kg-cm (389 oz-in) @ 6.0V
  • 33 kg-cm (458 oz-in) @ 7.4V
  • 36 kg-cm (500 oz-in) @ 8.4V


Operating Speed

  • 0.120sec/60° @ 4.8V
  • 0.110sec/60° @ 6.0V
  • 0.083sec/60° @ 7.4V
  • 0.071sec/60° @ 8.4V


  • Package Included

  • Item 1:
  • 1 x AGFRC A80BHSW V2 Waterproof Standard Servo
  • 1 x Accessory  Kit

  • Item 2:
  • 1 x AGFRC A80BHSW V2 Waterproof Standard Servo
  • 1 x 25T Black Metal Servo Horn
  • 1 x Accessory  Kit

  • Item 3:
  • 1 x AGFRC A80BHSW V2 Waterproof Standard Servo
  • 1 x AGF-SPV3 Servo Programmer
  • 1 x 25T Black Metal Servo Horn
  • 1 x Accessory  Kit



Brand:
AGFRC
Iterm Name:
A80BHSW V2
Control System:
Pulse Width Modulation Control (PWM)
Refresh Rate:
333Hz
Neutral Position:
1520uS
Signal Mode:
Digital
Dead band:
2 uSec
Operating Voltage:
4.8V ~ 8.4V
Operating Travel:
180°±10°
Signal Range:
500 to 2500 uSec
Angle Sensor:
Magnet Angle Sensor
Operating Temperature:
-15C°~ +70C°
Mechanical Angle:
No Limit
Waterproof Level:
IP67
Motor Type:
Brushless
Motor Drive:
FET Drive
Horn Gear Spline:
25T-φ5.92mm
Programmable:
Yes
Bearing:
Three Ball Bearings
Bearing Material:
Metal
Gear Material:
Strength Steel
Case Material:
Aluminium AL6061T6
Certification:
CE,FCC,RoHs
Product Size:
40*20*37.2mm(1.57*0.79*1.46in)
Wire Guage:
TYU 300mm / 22AWG
Net Weight:
79g(2.79oz)
