B45CHM V2 Low Profile 18kg High TorqueDigital Coreless Servo
With sufficient stock, packages will be shipped within 2 working days.
Insufficient stock, we will inform you as soon as the lead time is confirmed.
The package is expected to be delivered within 4 - 9 days after shipment.
Product Tag:
Low ProfileAGFRC B45CHM V2 Low Profile 18kg High Torque Digital Coreless Servo
➤ AGFRC B45CHM V2 180 degree potentiometer angle sensor programmable digital low profile servo, with coreless motor driven, 4.8-8.4V nominal operating voltage. The middle CNC aluminium case provides a good heat dissipation function and the appropriate temperature in operation.
MAIN FEATURES
➤ Plastic + CNC Aluminium Case.
➤ Metal Double Ball Bearings.
➤ Potentiometer Angle Sensor.
➤ Smoother Operation Coreless Motor.
➤ Steel Gear And Titanium Gears.
SPECIFICATIONS
Operating Voltage
4.8V - 8.4V
Temperature Range
-15°C - +70°C
Refresh Rate
1520 µS / 333Hz
Travel Angle
180 ± 10°
Programmable
Yes
Case Material
Aluminum + Plastic
Gear Material
Strength Steel
Sensor Type
Potentiometer
Motor Type
Coreless
Bearing
2BB
Direction
CCW
Horn Gear Spline
25T-ɸ5.92 mm
Wire
JR 190mm / 22AWG
Wire Color
Dimensions
40*20.2*26.5mm
Weight
48g
Operating Speed
0.140 sec/60° @4.8V
0.130 sec/60° @6.0V
0.120 sec/60° @7.4V
0.110 sec/60° @8.4V
Stall Torque
11.0 kg·cm (153 oz·in) @4.8V
13.0 kg·cm (180 oz·in) @6.0V
16.0 kg·cm (222 oz·in) @7.4V
18.0 kg·cm (250 oz·in) @8.4V
PACKAGE INCLUDES
➤ 1 x B45CHM V2 Servo
➤ 2 x 25T Plastic Horn
➤ 4 x Mounting Screw
➤ 1 x Horn Screw
➤ 4 x Rubber Pad
➤ 4 x Copper Sleeve
