Fast Speed 17.5KG 0.061Sec Standard Size Helicotper HV Digital Brushless RC Rubber Tail Servo with 666Hz Frequency (A73BHNH Tail)
AGFRC Fast Speed 17.5KG 0.061Sec Standard Size Helicotper HV Digital Brushless RC Rubber Tail Servo With 666Hz Frequency (A73BHNH Tail)
AGFRC A73BHNH Tail lightning fast powerful performance 25T splines standard digital servo for helicopters, designed in CNC metal servo case, servo could keep cool working temperature during use and look clean and tidy. Featured with brushless motor, metal gears and double ball bearings, it has a robust internal structure and greatly improves durability. With 0.068sec speed and 17.5kg high torque at 8.4V and 666Hz high Refresh Rate, it could very quick and accurately respond to each command.
Feature
666Hz High Refresh Rate
Metal Double Ball Bearings
Good stability Brushless Motor
Precision Potentiometer Angle Sensor
High Accuracy Strength Steel+Titanium Gear
High Performance Digital Servo Perfect For 450-700 Class Helicopter
Specification
Model Name: A73BHNH Tail
Operating Voltage: 4.8-8.4 V
Operating Speed: 0.085sec/60°@ 4.8V
Operating Speed: 0.075sec/60°@ 6.0V
Operating Speed: 0.068sec/60°@ 7.4V
Operating Speed: 0.061sec/60°@ 8.4V
Stall Torque: 14.0 kg-cm (194 oz-in) @ 4.8V
Stall Torque: 15.0 kg-cm (208 oz-in) @ 6.0V
Stall Torque: 16.5 kg-cm (229 oz-in) @ 7.4V
Stall Torque: 17.5 kg-cm (243 oz-in) @ 8.4V
Gear: Strength Steel + Titanium
Motor: Brushless
Size: 40*20*37.5mm (1.57 x 0.78 x 1.46 in)
Weight: 73.5g
Connector Wire: JR 300mm / 22AWG
Note: All the price in our store does not include any tax or vat.
- Brand:
- AGFRC
- Iterm Name:
- A73BHNH Tail
- Signal Mode:
- Digital
- Control System:
- Pulse Width Modulation Control (PWM)
- Refresh Rate:
- 666Hz
- Neutral Position:
- 760uS
- Dead band:
- 2 uSec
- Operating Voltage:
- 4.8V ~ 8.4V
- Operating Travel:
- 180°±10°
- Pulse width:
- 500 to 2500 uSec
- Operating Temperature:
- -15C°~ +70C°
- Mechanical Angle:
- 220°
- Angle Sensor:
- Potentiometer
- Motor Type:
- Brushless
- Motor Drive:
- FET Drive
- Horn Gear Spline:
- 25T-φ5.92mm
- Programmable:
- No
- Bearing:
- Dual Ball Bearings
- Bearing Material:
- Metal
- Gear Material:
- Titanium +Copper
- Case Material:
- Aluminium AL6061T6
- Certification:
- CE,FCC,RoHs
- Wire Guage:
- JR 300mm /22AWG
- Net Weight:
- 73.5g (2.59oz)
- Product Size:
- 40*20*37.5mm(1.57*0.79*1.48in)
