Metal Case 30KG 0.095Sec High Torque Dedicated RC Helicotper Brushless Standard Size Cyclic Servo (A73BHLH Cyclic)
AGFRC Metal Case 30KG 0.095Sec High Torque Dedicated RC Helicotper Brushless Standard Size Cyclic Servo (A73BHLH Cyclic)
AGFRC A73BHLH black and red edition nice looking 30kg torque 0.095sec speed standard digital Cyclic Servo, make in good heat dissipation CNC aluminum body for cooler and smoother operating temps. Features an reliable brushless motor, sturdy steel and titanium gear for unmatched performance and strength. With the help of 30kg-cm powerful torque, it could easy to control pitch and roll for the helicopter. Enhanced the potentiometer angle sensor to ensure the servo motor could work well.
If you are also looking for a Tail servo, you could please go for A73BHNH Tail Servo: https://www.agfrc.com/index.php?id=2734
Feature
Smooth Double Ball Bearings
8.4V High Voltage Compatible
Good stability Brushless Motor
Precision Potentiometer Angle Sensor
High Accuracy Strength Steel+Titanium Gear
High Performance Digital Servo Perfect For 450-700 Class Helicopter
Specification
A73BHLH Cyclic
Operating Voltage: 4.8-8.4 V
Operating Speed: 0.150sec/60°@ 4.8V
Operating Speed: 0.130sec/60°@ 6.0V
Operating Speed: 0.110sec/60°@ 7.4V
Operating Speed: 0.095sec/60°@ 8.4V
Stall Torque: 22 kg-cm (305 oz-in) @ 4.8V
Stall Torque: 24 kg-cm (333 oz-in) @ 6.0V
Stall Torque: 27 kg-cm (375 oz-in) @ 7.4V
Stall Torque: 30 kg-cm (417 oz-in) @ 8.4V
Gear: Strength Steel + Titanium
Motor: Brushless
Size: 40*20*37.5mm (1.57 x 0.78 x 1.46 in)
Weight: 72.0g
Connector Wire: JR 300mm / 22AWG
Note: All the price in our store does not include any tax or vat.
- Brand:
- AGFRC
- Iterm Name:
- A73BHLH Cyclic
- Signal Mode:
- Digital
- Control System:
- Pulse Width Modulation Control (PWM)
- Refresh Rate:
- 333Hz
- Neutral Position:
- 1520uS
- Dead band:
- 2 uSec
- Operating Voltage:
- 4.8V ~ 8.4V
- Operating Travel:
- 180°±10°
- Pulse width:
- 500 to 2500 uSec
- Operating Temperature:
- -15C°~ +70C°
- Mechanical Angle:
- 220°
- Angle Sensor:
- Potentiometer
- Motor Type:
- Brushless
- Motor Drive:
- FET Drive
- Horn Gear Spline:
- 25T-φ5.92mm
- Programmable:
- No
- Bearing:
- Dual Ball Bearings
- Bearing Material:
- Metal
- Gear Material:
- Titanium +Copper
- Case Material:
- Aluminium AL6061T6
- Certification:
- CE,FCC,RoHs
- Wire Guage:
- JR 300mm /22AWG
- Net Weight:
- 73.5g (2.59oz)
- Product Size:
- 40*20*37.5mm(1.57*0.79*1.48in)
