A27CHR Wing Servo Aluminum Case 10.2KG 0.10Sec Slim Size AGFRC RC Glider Digital MG Wing Servo
With sufficient stock, packages will be shipped within 2 working days.
Insufficient stock, we will inform you as soon as the lead time is confirmed.
The package is expected to be delivered within 4 - 9 days after shipment.
A27CHR 11KG High Torque 0.11Sec HV Coreless CNC Case With Super Strong Steel Gear 10mm Wing Servo For RC Gliders
➤ AGFRC wing servo series has added a new member, A27CHR. It adopts a CNC shell design, and can reach a large torque of 11KG and a speed of 0.11Sec when the voltage is as high as 8.4V. Moreover, the thickness of this high-performance programmable digital wing servo is only 10mm, and the lightweight and thin design saves more space and weight. The high-quality coreless motor and reliable dual ball bearing cooperate with the strong reinforced steel gear. It is believed that the model will be very smooth and stable when using the A27CHR.
MAIN FEATURES
➤ High Performance Digital Wing servo.
➤ Super Strong Steel Gear.
➤ High Quality Coreless Motor.
➤ Ultra Reliable Dual Ball Bearing.
➤ Full CNC Aluminium Case Design.
➤ Ideal For Airplane, gliders, drones, Jets, float planes, Sport Plane, Cars, Boats, etc.
SPECIFICATIONS
Operating Voltage
4.8V - 8.4V
Temperature Range
-15°C - +70°C
Refresh Rate
1520 µS / 333Hz
Travel Angle
180 ± 10°
Programmable
Yes
Case Material
Aluminum
Gear Material
Strength Steel
Sensor Type
Potentiometer
Motor Type
Coreless
Bearing
2BB
Direction
CCW
Horn Gear Spline
25T-ɸ4.94 mm
Wire
TYU 180mm / 26AWG
Wire Color
Dimensions
30*10*35.5mm
Weight
27.6g
Operating Speed
0.170 sec/60° @4.8V
0.150 sec/60° @6.0V
0.120 sec/60° @7.4V
0.110 sec/60° @8.4V
Stall Torque
7.5 kg·cm (104 oz·in) @4.8V
8.2 kg·cm (114 oz·in) @6.0V
10.0 kg·cm (139 oz·in) @7.4V
11.0 kg·cm (153 oz·in) @8.4V
PACKAGE INCLUDES
➤ 1 x A27CHR Servo
➤ 4 x 25T Plastic Horns
➤ 3 x Mounting Screw
➤ 1 x Horn Screw
➤ Perhaps you will need a spec datasheet or other related documents of the products. If there is a download button, it means you can simply click to download. We will continuously update the latest files for each product.
➤ If you do not find the file you want, please feel free to contact shopping@agfrc.com directly.
