B11DLS AGF High Torque 2.2-2.8KG.CM 0.12sec/60° 0.10sec/60° 11g Digital Metal Gear Servo Motor

stars, based on 1reviews
$14.40 [ 2 piece / Lot ]
100items available
Contact Us
不能存图片

SERVO B11DLS HIGH PRECISION MICRO SERVO FOR RC PLANE

SERVO B11DLS DATA SHEET

SERVO B11DLS Control System PWM 1520uS / 333Hz

SERVO B11DLS Operating Voltage 4.8V ~ 6.0V

SERVO B11DLS Operating Temperature -20C°~ +60C°


SERVO B11DLS Torque

2.2kg.cm At 4.8V

2.8kg.cm  At 6.0V


SERVO B11DLS Unload Speed

0.12sec / 60° At 4.8V

0.10sec / 60° At 6.0V


SERVO B11DLS Unload Current

200mA  At 4.8V

220mA  At 6.0V


SERVO B11DLS Loading Current

1000mA At 4.8V

1200mA   At 6.0V


SERVO B11DLS Dead band 4 usec

SERVO B11DLS Life Time >15000 times/ unload

SERVO B11DLS Angle 55°±5°

SERVO B11DLS Direction CCW

SERVO B11DLS Motor Drive IC Drive

SERVO B11DLS Motor Type DC

SERVO B11DLS Angle Sensor Potentiometer

SERVO B11DLS Signal Digital

SERVO B11DLS Programmable   No

SERVO B11DLS Bearing Metal

SERVO B11DLS Gear Material Copper

SERVO B11DLS Case Material Plastic

SERVO B11DLS Waterproof IP65

SERVO B11DLS Dimension 23*12.1*23.8mm

SERVO B11DLS Net Weight 13g (excluding accessory)


SERVO B11DLS Wire

Gauge 26AWG

Wire Length 180mm

Negative Black

Positive Red

Signal White
