AGFRC A81BMWP Advanced Ultra Power Pro 55KG Large Torque Brushless Standard Size Servo

4 / 5

AGFRC A81BMWP Advanced Ultra Power Pro 55KG Large Torque Brushless Standard Size Servo

stars, based on 0 reviews

Estimated Standard shipping time is about 4 ~ 8 days

For the inventory goods, the package will be dispatched within 3 working days

Product Tag:

AGFRC Brushless Standard Digital Servo For RC Car Boat Airplane etc (A81BMWP)

This new standard case 55kg servo A81BMWP is a PRO version A81BHMW, keeping the same size but with superb powerful motor, suitable for professional competition drivers who pursue the ultimate and extreme, or for the project engineer with limit budget but with high quality requirements.

Full aluminum case and structure, hardened steel gears, and an advanced motor, excellent linearity and precision control. All these are optimized to allow the servo to produce 55 kg 0.087 sec spec at 8.4V regular voltage. The servo is particularly suitable for large rc cars and giant aircraft and other demanding applications with an emphasis on high thrust and accuracy. Super fast response of the control electronics and high long-term durability.

Withstands immersion in water to a depth of 1 m for a 30-minute test run, it is suitable for off-road models of cars, ships, and submarines - simply for places exposed to the effects of dust and moisture, with high demands on the tensile strength and overall mechanical resistance of the servo.

Main Features

• Smooth Three Ball Bearings

• Fine Machining Aluminum Shell

• Steel Gear and Structure

• High Efficiency Long Life Brushless Motor

• IP67 Waterproof & Dust-proof

Specifications

Operating Voltage

4.8V - 8.4V

Temperature Range

-15°C - +70°C

Refresh Rate

1520 µS / 333Hz

Travel Angle

180 ± 10°

Programmable

Yes

Case Material

Aluminum

Gear Material

Strength Steel

Position Sensor

Magnet Angle Sensor

Motor Type

Brushless

Bearing

3BB

Direction

CCW

Horn Gear Spline

25T-ɸ5.92 mm

Wire

TYU 300mm / 22AWG

Wire Color

Dimensions

40*20*37.5mm

Weight

83g

Operating Speed

0.145 sec/60° @4.8V

0.125 sec/60° @6.0V

0.100 sec/60° @7.4V

0.087 sec/60° @8.4V

Stall Torque

32 kg·cm (444 oz·in) @4.8V

39 kg·cm (542 oz·in) @6.0V

48 kg·cm (667 oz·in) @7.4V

55 kg·cm (764 oz·in) @8.4V

Package Includes

Servo

1 x A81BMWP Servo

Plastic Horn

3 x 25T Plastic Horn

Screw

4 x Mounting Screw

1 x Servo Horn Screw

Download

• Perhaps you will need a spec datasheet or other related documents of the products. If there is a download button, it means you can simply click to download. We will continuously update the latest files for each product.

• If you do not find the file you want, please feel free to contact shopping@agfrc.com directly.

Download

Spec Datasheet

AGF A81BVMW Servo

Newest Firmware

Suitable for V3 Programming Software
