A86BUMW 4S 66KG 0.110Sec Hight Torque Monster Torque Waterproof Brushless Servo For 1/8 Scale RC Build

4 / 5

A86BUMW 4S 66KG 0.110Sec Hight Torque Monster Torque Waterproof Brushless Servo For 1/8 Scale RC Build

With sufficient stock, packages will be shipped within 2 working days.

Insufficient stock, we will inform you as soon as the lead time is confirmed.

The package is expected to be delivered within 4 - 9 days after shipment.

AGFRC 4S LiPo 66Kg High Torque 0.100 Sec Speed Monster Torque Waterproof Brushless Programmable Servo (A86BUMW)

➤ AGFRC A86BUMW is a standard-sized, fully metal-shell waterproof servo that can handle a high input voltage of 17V. While maintaining the usual attractive appearance of the AGFRC servo, it is equipped with three ball bearings, high-performance magnetic sensors, and a brushless motor. These make it a perfect match for those who demand the very best for their Crawler Cars, Truggy, Buggy, on or off road application.

➤ The A86BUMW has a high torque of 66KG and maintains a speed control of 0.100Sec, ensuring that you can enjoy the ultimate experience when using it.

MAIN FEATURES

➤ Fully CNC Aluminium Case.

➤ High Precision Magnetic Angle Sensor.

➤ Waterproof Up to IP67 Grade.

➤ Extremely Strong Patent Steel Gears.

➤ Long Lifespan Brushless Motor.

➤ Programmable Digital Circuit.

SPECIFICATIONS

Operating Voltage

7.4V - 17V

Temperature Range

-15°C - +70°C

Refresh Rate

1520 µS / 333Hz

Travel Angle

180 ± 10°

Programmable

Yes

Case Material

Aluminum

Gear Material

Strength Steel

Sensor Type

Magnetic Sensor

Motor Type

Brushless

Bearing

3BB

Direction

CCW

Horn Gear Spline

25T-ɸ5.92 mm

Wire

TYU 300mm / 22AWG

Wire Color

Dimensions

40*20*41.5mm

Weight

90.5g

Operating Speed

0.130 sec/60° @12.0V

0.115 sec/60° @14.4V

0.108 sec/60° @16.0V

0.100 sec/60° @16.8V

Stall Torque

46 kg·cm (639 oz·in) @12.0V

55 kg·cm (764 oz·in) @14.4V

62 kg·cm (861 oz·in) @16.0V

66 kg·cm (917 oz·in) @16.8V

PACKAGE INCLUDES

➤ 1 x A86BUMW Servo

➤ 1 x 25T Metal Horn

➤ 2 x 25T Plastic Horn

➤ 4 x M3*12mm Screw

➤ 1 x M3*8mm Screw

➤ 2 x M2*8mm Screw

➤ 4 x 9*6.9*5.6mm Rubber Pad

➤ 4 x φ6*φ3.5*5mm Copper Sleeve

➤ 1 x Silicon JST (Male) to XH2.5 4-Pin (Female) Adapter Cable, 20AWG, 10cm

➤ 1 x Silicon JST (Male) to XH2.5 5-Pin (Female) Adapter Cable, 20AWG, 10cm

➤ 1 x AGFRC Logo Sticker

➤ Perhaps you will need a spec datasheet or other related documents of the products. If there is a download button, it means you can simply click to download. We will continuously update the latest files for each product.

➤ If you do not find the file you want, please feel free to contact shopping@agfrc.com directly.
