B05CLS 5g Metal Gear 0.075Sec Hi Speed RC Drift Racing Coreless Micro Digital Servo Motor
In stock: ships within 2 business days.
Low stock: lead time confirmed upon order.
Delivery: 4–9 days after shipment.
AGFRC B05CLS 5g Metal Gear 0.075Sec Hi Speed RC Drift Racing Coreless Micro Digital Servo Motor
➤ If you are looking for a 20T metal gear high torque micro servo for your 1/28 RC Cars, then you should have a look at our B05CLS servo. This is a servo made in high efficient coreless motor to make sure 1.0 kg-cm torque and 0.075sec speed when the voltage is 6.0V, featuring a copper gear, a potentiometer angle sensor, a 120-degree travel angle, and a 200 degree mechanical angle. It is a compact-sized and lightweight servo for 1/28 RC Cars and small-scale planes.
MAIN FEATURES
➤ High Precision Metal Gears.
➤ Compact Size and Light Weight.
➤ Reliable and Strong Metal Gears.
➤ High Quality Coreless Motor.
➤ Powerful and Fast Speed.
➤ Perfect for 1/28 RC Cars (Mini-Q, WLtoys 1/28 K989, K969, P929 Series, Atomic AMZ & Other 1/28 Cars), Robot, EPP E3P Airplane Indoors, Mini RC Drone Aircraft Helicopter.
SPECIFICATIONS
Operating Voltage
3.6V - 6.5V
Temperature Range
-10°C - +50°C
Refresh Rate
1520 µS / 333Hz
Travel Angle
120 ± 10°
Programmable
No
Case Material
Plastic
Gear Material
Copper
Sensor Type
Potentiometer
Motor Type
Coreless
Bearing
- -
Direction
CCW
Horn Gear Spline
20T-ɸ3.92 mm
Wire
JR 150mm / 28AWG
Wire Color
Dimensions
21.3 x 11.5 x 17.6mm
Weight
8.0 g
Operating Speed
0.085 sec/60° @4.8V
0.075 sec/60° @6.0V
Stall Torque
0.9 kg·cm (12.5 oz·in) @4.8V
1.0 kg·cm (13.9 oz·in) @6.0V
PACKAGE INCLUDES
➤ 1 x B05CLS Servo
➤ 4 x 25T Plastic Horn
➤ 2 x Mounting Screw
➤ 1 x Horn Screw
➤ Perhaps you will need a spec datasheet or other related documents of the products. If there is a download button, it means you can simply click to download. We will continuously update the latest files for each product.
➤ If you do not find the file you want, please feel free to contact shopping@agfrc.com directly.
