AGFRC
AGFRC SA33 33KG IP67 Waterproof Brushless Digital Servo
In stock: ships within 2 business days.
Low stock: lead time confirmed upon order.
Delivery: 4–9 days after shipment.
AGFRC SA33 SA66BHLW 33KG IP67 Waterproof Brushless Digital Servo with Magnetic Angle Sensor Strength Steel Gears Programmable PWM and 25T Spline for 1/8 and 1/10 RC Models
➤ The AGFRC SA33, also identified as SA66BHLW, is a compact IP67 waterproof brushless digital servo for higher-load RC steering and mechanical-control applications. It delivers up to 33kg-cm at 8.4V with a fast 0.068 sec/60° response, while magnetic angle sensing and programmable PWM control support accurate and repeatable positioning.
➤ The SA33 combines strength steel gears, an aluminum case, metal bearings and a 25T Ø5.92mm spline in a 66g package. Its output makes it a market-based candidate for 1/8 and 1/10 RC cars, trucks, crawlers, boats and robotics after verifying mounting dimensions, power requirements and control load.
Main Features
● 33KG High-Torque Output at 8.4V
● 0.068s/60° High-Speed Response at 8.4V
● 4.8V–8.4V Operating Voltage
● IP67 Waterproof Protection
● Brushless Motor with FET Drive
● Magnetic Angle Sensor Feedback
● Strength Steel Gears and Aluminum Case
● Programmable PWM Control with 25T Spline
Applications
➤ Recommended for 1/8 and 1/10 RC cars trucks crawlers boats and robotics after verifying power-system compatibility mounting dimensions and control load.
Specifications
Operating Voltage
4.8V - 8.4V
Temperature Range
-15°C - +70°C
Refresh Rate
1520 µS / 333Hz
Travel Angle
180 ± 10°
Programmable
Yes
Case Material
Aluminum
Gear Material
Strength Steel
Sensor Type
Magnetic Sensor
Motor Type
Brushless
Bearing
2BB
Direction
CCW
Horn Gear Spline
25T-ɸ5.92 mm
Wire
TYU 300mm / 22AWG
Wire Color
Dimensions
40.8*20.2*26.5mm (1.61 × 0.80 × 1.04 in)
Weight
66 g (2.33 oz)
Operating Speed
0.110 sec/60° @4.8V
0.090 sec/60° @6.0V
0.080 sec/60° @7.4V
0.068 sec/60° @8.4V
Stall Torque
20 kg·cm (278 oz·in) @4.8V
25 kg·cm (347 oz·in) @6.0V
30 kg·cm (417 oz·in) @7.4V
33 kg·cm (458 oz·in) @8.4V
Package Includes
● 1 x SA33 Servo
● 1 x 25T Metal Horn
● 3 x 25T Plastic Horns
● 4 x M3 * 12mm Screws
● 1 x M3 * 8mm Screw
● 2 x M2 * 8mm Screws
● 4 x Rubber Pads
● 4 x Copper Sleeves
● 1 x AGFRC Logo Sticker
➤ Perhaps you will need a spec datasheet or other related documents of the products. If there is a download button, it means you can simply click to download. We will continuously update the latest files for each product.
➤ If you do not find the file you want, please feel free to contact shopping@agfrc.com directly.
