AGFRC
180 Degree 2.8KG Upgrade Steel Gear Digital Micro Servo(B11DLS)
stars, based on 1 reviews
Estimated Standard shipping time is about 4 ~ 8 days
For the inventory goods, the package will be dispatched within 3 working days
AGFRC 180 Degree 2.8KG Upgrade Steel Gear Low Voltage Digital Micro Throttle Steering 11g RC Servo (B11DLS)
AGFRC B11DLS 21T Micro High Torque Servo, with a brushed motor, single bearing, and steel gear to keep the smooth operation. It is a high-performance digital circuit micro servo, it can reach 2.8 kg-cm high torque and a 0.10sec speed at 6.0V.
Ideal for Car, Airplane, Helicopter, Robot
MAIN FEATURES
• High Performance Digital Servo
• Upgrade Reliable Steel Gear
• High Quality Brushed Motor
SPECIFICATIONS
Operating Voltage
4.8V - 6.0V
Temperature Range
-15°C - +70°C
Refresh Rate
1520 µS / 333Hz
Travel Angle
180° ± 10°
Programmable
No
Case Material
Plastic
Gear Material
Strength Steel
Position Sensor
Potentiometer
Motor Type
DC
Bearing
--
Direction
CCW
Horn Gear Spline
21T-ɸ4.9
Wire
JR 180mm / 26AWG
Wire Color
Dimensions
23*12.1*23.8mm
Net Weight
14.6g
Operating Speed
0.120 sec/60° @4.8V
0.110 sec/60° @6.0V
Stall Torque
2.2 kg·cm (30 oz·in) @4.8V
2.8 kg·cm (39 oz·in) @6.0V
PACKAGE INCLUDES
Servo
1 x B11DLS Servo
Plastic Horn
4 x 21T Plastic Horn
Screw
2 x Mounting Screw
1 x Servo Horn Screw
By
Scott Saylors
Monday, 08 June 2020Got two of them and installed one in my SCX24 and it is like night and day compared to stock. Going to install 4WS soon with the second one
