Superb Performance HV Aluminum Case Low Profile Brushless Servo (A62BHS)

stars, based on 0 reviews
200items available
Contact Us

 AGFRC Superb Performance HV Aluminum Case  Low Profile Brushless Servo (A62BHS)


AGFRC A62BHS digital brushless programmable low profile servo. This high-performance servo is designed with a heat sink CNC case, which can prevent hot and stuffy phenomena when the model is running.


Feature

High Performance Low Profile Digital Servo

High Precision Steel Gears

Long Lifespan Brushless Motor

Heat Sink Aluminum Case

Programmable Digital Circuit


Specification

Item Name: A62BHS

Operating Voltage: 4.8-8.4V

Operating speed: 0.070sec/60° @ 6.0V

Operating speed: 0.065sec/60° @ 7.4V

Operating speed: 0.058sec/60° @ 8.4V

Stall Torque: 13.0 kg-cm (180 oz-in) @ 6.0V

Stall Torque: 14.5 kg-cm (201 oz-in) @ 7.4V

Stall Torque: 16.0 kg-cm (222 oz-in) @ 8.4V

Gear: Steel

Motor: BLS

Size: 40.8*20.2*26.5mm (1.60 x 0.79 x 1.04 in)

Weight: 57.2g

Connector Wire: TYU 200mm / 22AWG


Brand:
AGFRC
Item Name:
A62BHS
Control System:
Pulse width modulation control
Refresh Rate:
333Hz
Neutral Position:
1520uS
Signal Mode:
Digital
Dead band:
2 uSec
Operating Voltage:
4.8V ~ 8.4V
Operating Temperature:
-15C°~ +70C°
Bearing:
Dual Ball Bearing
Operating Travel:
180°±10°
Signal Range:
500 to 2500 uSec
Angle Sensor:
Potentiometer
Mechanical Angle:
220°
Motor Type:
Brushless
Motor Drive:
FET Drive
Horn Gear Spline:
25T-φ5.92mm
Programmable:
Yes
Bearing Material:
Metal
Gear Material:
Strength Steel+Titannium
Case Material:
AL6061T6
Certification:
CE,FCC,RoHs
Product Size:
40.8*20.2*26.5mm (1.61*0.80*1.04 inch)
Wire Guage:
JR 180mm /22AWG
Net Weight:
57.3g(2.02oz)
