A35CHM 12.5kg 0.085Sec Coreless Programmable High Torque Mini Servo
With sufficient stock, packages will be shipped within 2 working days.
Insufficient stock, we will inform you as soon as the lead time is confirmed.
The package is expected to be delivered within 4 - 9 days after shipment.
Product Tag:
Mini ServoAGFRC 12.5kg 0.085Sec Speed Coreless Programmable High Torque Mini Servo(A35CHM)
➤ A35CHM is a 12.5kg digital medium-sized servo. More efficient coreless motor to support fast response time of servo, so this servo can operate at a 0.085sec fast speed when the voltage is 8.4V. An aluminum case for better heat dissipation. Programmable function is an essential feature for those who like to create unique servos. It is ideal for the use of RC Cars and Planes.
MAIN FEATURES
➤ High Performance Digital Servo.
➤ High Precision Titanium Gear.
➤ Fully CNC aluminum Case.
➤ High Quality Coreless Motor.
➤ Programmable & Easy to Program.
SPECIFICATIONS
Operating Voltage
4.8V - 8.4V
Temperature Range
-15°C - +70°C
Refresh Rate
1520 µS / 333Hz
Travel Angle
180 ± 10°
Programmable
Yes
Case Material
Aluminum
Gear Material
Titanium
Sensor Type
Potentiometer
Motor Type
Coreless
Bearing
2BB
Direction
CCW
Horn Gear Spline
25T-ɸ5.92 mm
Wire
TYU 180mm / 22AWG
Wire Color
Dimensions
35.5*15*29.2mm
Weight
41g
Operating Speed
0.145 sec/60° @4.8V
0.125 sec/60° @6.0V
0.095 sec/60° @7.4V
0.085 sec/60° @8.4V
Stall Torque
9.5 kg·cm (132 oz·in) @4.8V
10.5 kg·cm (146 oz·in) @6.0V
11.5 kg·cm (160 oz·in) @7.4V
12.5 kg·cm (174 oz·in) @8.4V
PACKAGE INCLUDES
➤ 1 x A35CHM Servo
➤ 4 x 25T Plastic Horns
➤ 4 x Mounting Screw
➤ 1 x Horn Screw
➤ 4 x Rubber Pad
➤ 4 x Copper Sleeve
➤ Perhaps you will need a spec datasheet or other related documents of the products. If there is a download button, it means you can simply click to download. We will continuously update the latest files for each product.
➤ If you do not find the file you want, please feel free to contact shopping@agfrc.com directly.
