AGFRC A35BHLP 22KG High-Speed Brushless Servo
In stock: ships within 2 business days.
Low stock: lead time confirmed upon order.
Delivery: 4–9 days after shipment.
AGFRC A35BHLP 22KG High-Speed Brushless Digital Servo with Strength Steel Gears Aluminum Case Programmable PWM Control and 25T Spline for 1/10 RC Cars Trucks and Robotics
➤ The AGFRC A35BHLP is a compact high-speed brushless digital servo for fast steering and control in RC models. It produces up to 22kg-cm at 8.4V and reaches 0.070 sec/60°, offering a strong speed-to-size ratio in a 46g body.
➤ Its brushless motor, FET drive, strength steel gears, aluminum case, metal bearings and programmable PWM control provide a responsive setup for compact vehicles and mechanisms. The 35.5 × 15 × 29.2mm body and 25T Ø5.92mm spline suit candidate applications in 1/10 RC cars, trucks, drift cars and robotics after verifying mounting and load requirements.
Main Features
● 22KG Torque at 8.4V
● 0.070s/60° High-Speed Response
● Compact 46g Form Factor
● Brushless Motor with FET Drive
● Strength Steel Gears
● Aluminum Case and Metal Bearings
● Programmable PWM Digital Control
● 25T Ø5.92mm Spline Compatibility
Applications
➤ Recommended for 1/10 RC cars trucks drift cars touring cars and compact robotics after verifying mounting dimensions power supply and steering load.
Specification
Operating Voltage
4.8V - 8.4V
Temperature Range
-15°C - +70°C
Refresh Rate
1520 µS / 333Hz
Travel Angle
180 ± 10°
Programmable
Yes
Case Material
Aluminum
Gear Material
Strength Steel
Sensor Type
Potentiometer
Motor Type
Brushless
Bearing
2BB
Direction
CCW
Horn Gear Spline
25T-ɸ5.92 mm
Wire
TYU 180mm / 26AWG
Wire Color
Dimensions
35.5*15*29.2 mm (1.40 × 0.59 × 1.15 in)
Weight
46 g (1.52 oz)
Operating Speed
0.105 sec/60° @4.8V
0.090 sec/60° @6.0V
0.080 sec/60° @7.4V
0.070 sec/60° @8.4V
Stall Torque
12.5 kg·cm (173 oz·in) @4.8V
15.8 kg·cm (219 oz·in) @6.0V
19.5 kg·cm (271 oz·in) @7.4V
22.0 kg·cm (305 oz·in) @8.4V
Package Includes
● 1 x A35BHLP Servo
● 4 x 25T Plastic Horns
● 4 x M2*12mm*φ5mm Screws
● 1 x M3*6mm*φ5.6mm Screw
● 4 x Rubber Pads
● 4 x Copper Sleeves
● 1 x AGFRC Logo Sticker
➤ Perhaps you will need a spec datasheet or other related documents of the products. If there is a download button, it means you can simply click to download. We will continuously update the latest files for each product.
➤ If you do not find the file you want, please feel free to contact shopping@agfrc.com directly.
