A06CLS V2 7g Aluminum Case 0.052Sec 3KG Super Speed Mini Coreless Servo for Small Size RC Model
With sufficient stock, packages will be shipped within 2 working days.
Insufficient stock, we will inform you as soon as the lead time is confirmed.
The package is expected to be delivered within 4 - 9 days after shipment.
AGFRC 7G 0.052Sec High Speed 3Kg Torque Mini Coreless Servo A06CLS V2 for Mini Z cars
➤ AGFRC A06CLS V2 is the upgrade version of the A06CLS servo, with high-voltage features. This servo is compatible to be used for use with small-sized airplanes and gliders. 7g super lightweight with a full CNC machining case. 2 µSec wide voltage which produces 3KG high torque and 0.052Sec super spec at 8.4V. JST and JR plug options allow them to be used for different models. Of course, the highlight "programmable" feature is still continuing for this lovely micro servo. Black edition and Purple edition are available.
MAIN FEATURES
➤ High Performance Mini Coreless Servo.
➤ 7g Lightweight.
➤ High Precision Titanium Gear.
➤ Fully CNC Aluminum Case.
➤ Programmable Digital Circuit.
➤ Design for mini z cars MRZ, 1/18, 1/24, 1/27, Scale Cars such as GL Racing GLD, GLA V2.1, GLR, GLF-1, GLR GT.
SPECIFICATIONS
Operating Voltage
4.8V - 8.4V
Temperature Range
-15°C - +70°C
Refresh Rate
1520 µS / 333Hz
Travel Angle
180 ± 10°
Programmable
Yes
Case Material
Aluminum
Gear Material
Titanium
Sensor Type
Potentiometer
Motor Type
Coreless
Bearing
BB
Direction
CCW
Horn Gear Spline
15T|20T-ɸ4.00 mm
Wire
JR|JST1.5 60mm / 28AWG
Wire Color
Dimensions
20*8*17.8mm
Weight
7g
Operating Speed
0.075 sec/60° @4.8V
0.066 sec/60° @6.0V
0.058 sec/60° @7.4V
0.052 sec/60° @8.4V
Stall Torque
1.8 kg·cm (25 oz·in) @4.8V
2.2 kg·cm (30 oz·in) @6.0V
2.6 kg·cm (36 oz·in) @7.4V
3.0 kg·cm (41 oz·in) @8.4V
PACKAGE INCLUDES
➤ 1 x A06CLS V2 Servo
➤ 2 x 15T|20T Plastic Horns
➤ 2 x Mounting Screw
➤ 1 x Horn Screw
➤ Perhaps you will need a spec datasheet or other related documents of the products. If there is a download button, it means you can simply click to download. We will continuously update the latest files for each product.
➤ If you do not find the file you want, please feel free to contact shopping@agfrc.com directly.
