18KG HV High Torque Low Profile Programmable Coreless Servo(A50CHM)
stars, based on 0reviews
不能存图片
AGFRC 18KG HV High Torque Low Profile Programmable Coreless Servo for 1:10 Scale on-road RC Drift Car RC Plane(A50CHM)
Feature
High performance Low Profile digital servo
High precision steel gears
High quality Coreless motor
Dual ball bearing
Progammable
Aluminum top and middium part
Ideal for 1/10, 1/12 on road car, airplane etc.
Stall Torque
- 11 kg-cm (153 oz-in) @ 5.0V
- 13 kg-cm (181 oz-in) @ 6.0V
- 16 kg-cm (222 oz-in) @ 7.4V
- 18 kg-cm (250 oz-in) @ 8.4V
Operating Speed
- 0.14sec/60° @ 5.0V
- 0.13sec/60° @ 6.0V
- 0.12sec/60° @ 7.4V
- 0.11sec/60° @ 8.4V
- Package Included
- Item 1:
- 1 x AGFRC A50CHM Low Profile Servo
- 1 x Accessory Kit
- Item 2:
- 1 x AGFRC A50CHM Low Profile Servo
- 1 x 25T Black Metal Servo Horn
- 1 x Accessory Kit
- Item 3:
- 1 x AGFRC A50CHM Low Profile Servo
- 1 x AGF-SPV3 Servo Programmer
- 1 x 25T Black Metal Servo Horn
- 1 x Accessory Kit
- Note: Item 1 and 2 does not include the AGF-SPV3 servo programmer.
- Brand:
- AGFRC
- Item Name:
- A50CHM
- Control System:
- Pulse width modulation control
- Refresh Rate:
- 333Hz
- Neutral Position:
- 1520uS
- Signal Mode:
- Digital
- Dead band:
- 2 uSec
- Operating Voltage:
- 4.8V ~ 8.4V
- Operating Temperature:
- -15C°~ +70C°
- Bearing:
- Dual Ball Bearing
- Operating Travel:
- 180°±10°
- Signal Range:
- 500 to 2500 uSec
- Angle Sensor:
- Potentiometer
- Mechanical Angle:
- 200°
- Motor Type:
- Coreless
- Motor Drive:
- FET Drive
- Horn Gear Spline:
- 25T-φ5.92mm
- Programmable:
- Yes
- Bearing Material:
- Metal
- Gear Material:
- Stainless Steel+Titannium
- Case Material:
- AL6061T6+Plastic
- Certification:
- CE,FCC,RoHs
- Wire Guage:
- JR 180mm /22AWG
- Net Weight:
- 50g (1.76 oz)
- Product Size:
- 40.8*20.2*26.5mm (1.61*0.80*1.04 inch)
