AGFRC A11CLS V3 1.4KG Micro Coreless Servo
In stock: ships within 2 business days.
Low stock: lead time confirmed upon order.
Delivery: 4–9 days after shipment.
AGFRC A11CLS V3 1.4KG 0.050sec Mini Coreless Digital Servo with Titanium Gears and Potentiometer Sensor
➤ The AGFRC A11CLS V3 is a compact and lightweight digital servo designed for micro RC models and space-constrained installations. It delivers up to 1.4 kg-cm of stall torque and an operating speed of 0.050 sec/60° at 6.0 V, supporting responsive control within a 4.8-6.0 V operating range.
➤ Featuring a coreless motor, IC drive, potentiometer angle sensor, titanium gears, 2BB bearings and an aluminum case, the A11CLS V3 combines quick response with an 11 g lightweight design. Its programmable PWM control, 20 x 11.3 x 21 mm body and 180° +/- 10° operating travel make it suitable for compact model applications.
Main Features
● Maximum stall torque of 1.4 kg-cm at 6.0 V
● Operating speed up to 0.050 sec/60° at 6.0 V
● Coreless motor with IC drive for fast response
● Lightweight 11 g design for micro RC installations
● Compact body measuring 20 x 11.3 x 21 mm
● Titanium gears with 2BB metal bearing support
● Programmable PWM digital control with a 333 Hz refresh rate and 2 μsec dead band
● Potentiometer angle sensor with a standard 25T-Ø4.94 mm spline
Applications
➤ Ideal for micro RC cars, model aircraft, small robots and other compact applications requiring lightweight, fast and programmable servo control.
Specifications
Operating Voltage
4.8V - 6.0V
Temperature Range
-15°C - +70°C
Refresh Rate
1520 μS / 333Hz
Travel Angle
180 ± 10°
Programmable
Yes
Case Material
Aluminum
Gear Material
Titanium
Sensor Type
Potentiometer
Motor Type
Coreless
Bearing
2BB
Direction
CCW
Horn Gear Spline
25T-ɸ4.94 mm
Wire
JR|JST1.5 80mm / 30AWG
Wire Color
Dimensions
20*11.3*21 mm (0.79 × 0.44 × 0.83 in)
Weight
11 g (0.39 oz)
Operating Speed
0.065 sec/60° @4.8V
0.050 sec/60° @6.0V
Stall Torque
1.2 kg·cm (17 oz·in) @4.8V
1.4 kg·cm (19 oz·in) @6.0V
Package Includes
● 1 x A11CLS V3 Servo
● 4 x 25T Plastic Horns
● 2 x Mounting Screw
● 1 x Horn Screw
