AGFRC A35BHLP 22KG Ultra Torque HV Digital Middle Size 25T Spline Metal Case Gear Brushless Servo for RC Car Airplane

Brushless 22KG Ultra Torque Mid-Size Servo A35BHLP

Application: Ideal for 1/12 Scale RC Cars, 380-500 Size Helicopter Cyclic, Glider, Car, Robot, etc.

With the continuous optimization of the manufacturing technique, recently AGFRC servos bring more and more surprises. The mini-sized servo A35BHLP with 15mm thickness can deliver 22KG super high torque now. Completely upgrade from 16KG to 22KG for this middle-class servo with PRO brushless motor.

Optimize from servo firmware to hardware, which with strong holding force in center position. Mainly use for air applications, but also used in some competition cars, trucks and boats which with weight and dimension requests. It combines power, precision with speed. The impressive performance has been proven by some professional pilots.

 ​Main Feature

• Full Aluminum Case and Structure
• 15mm Mid Servo Class
• Strong Holding Force
• 25T Standard Output Spline
• 2S LiPo Voltage Capable
• Long Lifespan Pro Brushless Motor
• Ideal for RC Cars, Helicopters, Airplanes, etc.

 ​Specification

• Model Name: A35BHLP
• Operating Voltage: 4.8V ~ 8.4V
• Motor Type: Brushless
• Gear Material: Steel Gear
• Shell Material: Full CNC Aluminum
• Dimensions: 35.5*15*29.2 mm
• Weight: 45g
• Connector Type: TYU 180mm or 360mm /22AWG

 ​Package Includes

Item 1:

• 1 x A35BHLP Servo
• 1 x Set of Mounting Hardware
• 1 x Set of Servo Horns (Plastic Horns)

Item 2:

• 1 x A35BHLP Servo
• 1 x Set of Mounting Hardware
• 1 x Set of Servo Horns (Plastic Horns)
• 1 x 25T Metal Horn (HSS20P2)

Item 3:

• 1 x A35BHLP Servo
• 1 x Set of Mounting Hardware
• 1 x Set of Servo Horns (Plastic Horns)
• 1 x 25T Metal Horn (HSS20P2)
• 1 x AGF-SPV3 Programmer

 ​Download

Spec Datasheet: Download
