AGFRC
A280BVSW 3/4S 16.8V 125KG Monster Torque 0.077Sec High Speed 3S/4S BLS Large Size Servo for 1/5 RC Truck /Buggy
With sufficient stock, packages will be shipped within 2 working days.
Insufficient stock, we will inform you as soon as the lead time is confirmed.
The package is expected to be delivered within 4 - 9 days after shipment.
A280BVSW 4S 16V Mega Torque 125KG 0.08Sec High Speed Programmable Brushless Waterproof 1/5 Giant Scale Servo
➤ A280BVSW is a large size 1/5 servo recently come out by AGFRC. It combines long-life brushless motor with monster torque design takes the driving experience of large model enthusiasts to a new level. It is ideal for 1/5 Monster Truck, Buggy, Crawler, Large Airplanes, Robot Arm, etc. Whether you are traversing the jungle or climbing over sand dunes, 5 ball bearings and strengthening gear structure improve the crashworthiness and life of the servo.
MAIN FEATURES
➤ Heat Sink Aluminum Case.
➤ Extremely Strong Steel Gears.
➤ Super Reliable Five Ball Bearing.
➤ 3S and 4S Lipo Compatible.
➤ Associated 15T Aluminum Servo Horns.
➤ Magnetic Sensor Waterproof IP67.
➤ Easy Connection With Direct Power Wire.
SPECIFICATIONS
Operating Voltage
7.4V - 16.8V
Temperature Range
-15°C - +70°C
Refresh Rate
1520 µS / 333Hz
Travel Angle
180 ± 10°
Programmable
Yes
Case Material
Aluminum
Gear Material
Strength Steel
Sensor Type
Magnetic Sensor
Motor Type
Brushless
Bearing
5BB
Direction
CCW
Horn Gear Spline
15T-ɸ7.8 mm
Wire
TYU+JST 300mm / 22AWG
Wire Color
Dimensions
65.8*30.0*59.0mm
Weight
284.3g
Operating Speed
0.120 sec/60° @10.0V
0.110 sec/60° @11.1V
0.100 sec/60° @12.0V
0.090 sec/60° @14.4V
0.080 sec/60° @16.0V
0.077 sec/60° @16.8V
Stall Torque
78 kg·cm (1084 oz·in) @10.0V
83 kg·cm (1153 oz·in) @11.1V
92 kg·cm (1278 oz·in) @7.4V
110 kg·cm (1528 oz·in) @14.4V
125 kg·cm (1736 oz·in) @16.0V
128 kg·cm (1779 oz·in) @16.8V
PACKAGE INCLUDES
➤ 1 x A280BVSW Servo
➤ 2 x 15T Metal Horn
➤ 4 x M3*15mm Screw
➤ 1 x M3*8mm Screw
➤ 1 x M2.5*6mm Screw
➤ 1 x M2.5*8mm Screw
➤ 2 x M2.5*12mm Screw
➤ 4 x φ3*φ5.5*8mm Rubber Pad
➤ 4 x Φ6.5*Φ3.5*Φ3.1*7mm Copper Sleeve
➤ 1 x AGFRC Logo Sticker
➤ Perhaps you will need a spec datasheet or other related documents of the products. If there is a download button, it means you can simply click to download. We will continuously update the latest files for each product.
➤ If you do not find the file you want, please feel free to contact shopping@agfrc.com directly.
