74KG Super Torque 4-Poles Brushless Programmable RC Servo(A81FHM)

stars, based on 0reviews
100items available
Contact Us
不能存图片

AGFRC 74 kg-cm (1028 oz-in) @ 8.4V High Torque 4-Poles Brushless Programmable Digital Steering Servo for 1/10 1/8 RC Crawler Buggy Truck (A81FHM)


Today we are going to introduce a new partner is the A81FHM programmable standard digital servo with 74KG super torque. The design feature of this new product is the use of high-quality 4-poles brushless motors, and the metal four bearing adopts dust-proof bearing, which effectively improve the product's sealing and dust-proof and splash-proof effects. In addition, its sturdy new shape CNC shell adopts a fast cooling design of the heat sink, which can achieve a good heat dissipation effect while the product is working and prevent the phenomenon of being hot. It is very suitable for scenes that require large torque applications, such as some large rc aircraft, 1/8 1/10 scale rc off-road vehicles, monster trucks, and crawler car competitions.


Feature

High Performance Digital Standard Powerful Servo

High Quality Long Lifespan 4-Poles Brushless Motor

Heat Sink Fast Cooling CNC Case Design

Enhanced Steel Gears And Pin Shaft

Strong Sealing And Dustproof Metal Four Bearings

High Precision 25T Horn Gear Spline

Support Programmable User Parameters

Ideal For 1/8 1/10 On-Road, Off-Road, Monster Truck, Large Size Plane, Helicopter, Robot And Engine Etc.


Stall Torque

          • 45 kg-cm (625 oz-in) @ 4.8V

            55 kg-cm (764 oz-in) @ 6.0V

            65 kg-cm (903 oz-in) @ 7.4V

            74 kg-cm (1028 oz-in) @ 8.4V


Operating Speed

        • 0.190sec/60° @ 4.8V

          0.165sec/60° @ 6.0V

          0.135sec/60° @ 7.4V

          0.125sec/60° @ 8.4V


Package included


Item 1:

  • 1 x AGFRC A81FHM Programmable Servo
  • 1 x 25T Black Metal Servo Horn
  • 1 x Accessory Kit

    • Item 2:

      • 1 x AGFRC A81FHM Programmable Servo
      • 1 x AGF-SPV2 Servo Programmer
      • 1 x 25T Black Metal Servo Horn
      • 1 x Accessory Kit

      • Note:1. Item 1 does not include the AGF-SPV2 servo programmer.
      •          2. This product price does not include EU VAT.




Brand:
AGFRC
Iterm Name:
A81FHM
Signal Mode:
Digital
Control System:
Pulse width modulation control
Refresh Rate:
333Hz
Neutral Position:
1520uS
Dead band:
2 uSec
Operating Voltage:
4.8V~8.4V
Operating Travel:
180°±10°
Mechanical Angle:
220°
Signal Range:
500 to 2500 uSec
Angle Sensor:
Potentiometer
Temperature:
-15C°~ +70C°
Motor Type:
4-Poles Brushless
Motor Drive:
FET Drive
Horn Gear Spline:
25T-φ5.92mm
Programmable:
Yes
Waterproof Level:
/
Bearing:
Four Ball Bearings
Bearing Material:
Metal
Gear Material:
Strength Steel
Case Material:
AL6061T6
Certification:
CE,FCC,RoHs
Wire Guage:
TYU 300mm / 22AWG
Net Weight:
85g(3.00oz)
Product Size:
40*20*38mm (1.57 x 0.78 x 1.5 in)
