AGFRC 68 kg-cm (945 oz-in) @ 8.4V High Torque IP67 Waterproof 4-Poles Brushless New Shape Design Programmable Digital Steering Smart Servo for 1/10 1/8 RC Crawler Buggy Truck (SA81FHSW)

Commit to make and provide higher quality and performance products for AGFRC fans. We launch a brand new and special A81F Series servos. SA81FHSW is a programmable smart servo.



Fully upgrade from design and material for the whole servo, incredibly hardened stainless steel gears and pin shaft, superb reliable dustproof and reliable four ball bearings, wide-voltage capability and monster power 4-pole brushless motor, which delivery much higher torque with only 38mm height. High precision magnetic encoder which allow the servo run in humid or rainy environment. Besides, it also continue programmable feature , which enable to adjust the servo parameter and change the servo mode by USB programmer for different application --- Steering/Throttle or Winch.



If your model with limit installation space, but require higher torque around 68KG. Here highly recommend our brand new and powerful superior servo A81FHS with monster spec 68KG 0.105Sec @ 8.4V, ideal choice for high power model.



If you use our A81BHMW/A81BHSW before, you shouldn’t miss it. It will bring you a superior driving feel.


Feature

Programmable HV Digital Servo

Full CNC Machining Case

Strengthened Stainless Steel Gears

New Ultra Strong 4-Pole Brushless Motor

Dust Resistant Four Ball Bearings

Reinforce Pin Shaft and Structure

2S LiPo Wide Voltage Capable

25T Output Spline

Magnetic Waterproof for Humid or Rainy Situation

Totally Green Material and Production

Smart Function Feature -Available to change the firmware for different usage

For All-purpose Giant Scale Airplanes, Jet, 1/5 Scale Throttle Servo, 1/8, 1/10 Scale Rock Crawler, Buggy, Truck, Truggy, Robot etc.


Stall Torque

        • 42 kg-cm (584 oz-in) @ 4.8V

          52 kg-cm (723 oz-in) @ 6.0V

          60 kg-cm (934 oz-in) @ 7.4V

          68 kg-cm (945 oz-in) @ 8.4V


Operating Speed

      • 0.160sec/60° @ 4.8V

        0.135sec/60° @ 6.0V

        0.120sec/60° @ 7.4V

        0.105sec/60° @ 8.4V


Package included


Item 1:

  • 1 x AGFRC SA81FHSW Programmable Smart Servo
  • 1 x 25T Black Metal Servo Horn
  • 1 x Accessory Kit

    • Item 2:

      • 1 x AGFRC SA81FHSW Programmable Smart Servo
      • 1 x AGF-SPV2 Servo Programmer
      • 1 x 25T Black Metal Servo Horn
      • 1 x Accessory Kit
      • Note:1. Item 1 does not include the AGF-SPV2 servo programmer.
      •          2. This product price does not include EU VAT.


Brand:
AGFRC
Iterm Name:
SA81FHSW
Signal Mode:
Digital
Control System:
Pulse width modulation control
Refresh Rate:
333Hz
Neutral Position:
1520uS
Dead band:
2 uSec
Operating Voltage:
4.8V~8.4V
Operating Travel:
180°±10°
Mechanical Angle:
No Limit
Signal Range:
500 to 2500 uSec
Angle Sensor:
Magnet Angle Sensor
Temperature:
-15C°~ +70C°
Motor Type:
4-Poles Brushless
Motor Drive:
FET Drive
Horn Gear Spline:
25T-φ5.92mm
Programmable:
Yes
Waterproof Level:
IP67
Bearing:
Four Ball Bearings
Bearing Material:
Metal
Gear Material:
Strength Steel
Case Material:
AL6061T6
Certification:
CE,FCC,RoHs
Wire Guage:
TYU 300mm / 22AWG
Net Weight:
85g(3.00oz)
Product Size:
40*20*38mm (1.57 x 0.78 x 1.5 in)
