AGFRC B53CHLW 32KG IP67 Coreless Digital Servo
In stock: ships within 2 business days.
Low stock: lead time confirmed upon order.
Delivery: 4–9 days after shipment.
AGFRC B53CHLW 32KG IP67 HV Programmable Coreless Digital Servo with Magnetic Angle Sensor
➤ The AGFRC B53CHLW is a standard-size HV coreless digital servo designed for strong RC steering performance with waterproof protection and accurate feedback sensing. It delivers up to 32 kg-cm of stall torque and 0.135 sec/60° speed at 8.4 V, while supporting a wide 4.8-8.4 V voltage range.
➤ Featuring an IP67 waterproof rating, magnetic angle sensor, no-limit mechanical angle, FET drive, strength steel gears, 2BB metal bearings and an aluminum + plastic case, the B53CHLW is built for demanding RC cars, trucks and crawlers used in wet, dusty or outdoor conditions.
Main Features
● Maximum stall torque of 32 kg-cm at 8.4 V
● Operating speed up to 0.135 sec/60° at 8.4 V
● IP67 waterproof protection for wet and dusty RC environments
● Magnetic angle sensor with no-limit mechanical angle design
● Coreless motor with FET drive for smooth digital response
● Strength steel gears with 2BB metal bearing support
● Programmable PWM control with 333 Hz refresh rate and 4 μsec dead band
● Standard 40 x 20 x 37.5 mm body with 25T-Ø5.92 mm spline
Applications
➤ Ideal for 1/8 and 1/10 scale RC cars, trucks, crawlers and outdoor RC vehicle builds that need a 32KG IP67 waterproof coreless steering servo.
Specifications
Operating Voltage
4.8V - 8.4V
Temperature Range
-15°C - +70°C
Refresh Rate
1520 µS / 333Hz
Travel Angle
180 ± 10°
Programmable
Yes
Case Material
Aluminum + Plastic
Gear Material
Strength Steel
Sensor Type
Magnetic Sensor
Motor Type
Coreless
Bearing
2BB
Direction
CCW
Horn Gear Spline
25T-ɸ5.92 mm
Wire
JR 300mm / 22AWG
Wire Color
Dimensions
40*20*37.5 mm (1.57 × 0.79 × 1.48 in)
Weight
69.5 g (2.45 oz)
Operating Speed
0.180 sec/60° @4.8V
0.160 sec/60° @6.0V
0.145 sec/60° @7.4V
0.135 sec/60° @8.4V
Stall Torque
22 kg·cm (306 oz·in) @4.8V
26 kg·cm (361 oz·in) @6.0V
29 kg·cm (403 oz·in) @7.4V
32 kg·cm (445 oz·in) @8.4V
Pacakge Includes
● 1 x B53CHLW Servo
● 2 x 25T Plastic Horns
● 4 x Mounting Screws
● 1 x Horn Screw
● 4 x Rubber Pads
● 4 x Copper Sleeves
➤ Perhaps you will need a spec datasheet or other related documents of the products. If there is a download button, it means you can simply click to download. We will continuously update the latest files for each product.
➤ If you do not find the file you want, please feel free to contact shopping@agfrc.com directly.
