A80BHX-H Metal Gears 0.06sec Fast Speed 30KG High Torque Brushless RC Swashplate Cyclic Servo for Helicopter
With sufficient stock, packages will be shipped within 2 working days.
Insufficient stock, we will inform you as soon as the lead time is confirmed.
The package is expected to be delivered within 4 - 9 days after shipment.
AGFRC A80BHX-H Swash Plate 30KG 0.038Sec High Torque 8.4V High Voltage Brushless Helicopter Cyclic Servo
➤ Fans of RC helicopters, your long-awaited new Cyclic helicopter servo AGFRC A80BHX-H is coming!
➤ It is an 8.4V high voltage and 30KG high torque cyclic swash plate high-performance standard digital helicopter servo. Full CNC aluminium case and super strong steel gear satisfy every crazy flight. When you need more flight training, a long-lifespan brushless motor and high-strength three-ball metal bearings can bring you a silky flight like chocolate. Oh! Don't forget that it's 0.038sec fast speed, which is an essential speed for fun in flight. All processes from raw materials to production are environmentally friendly and green. It is very suitable for OXY5 MEG, SAB GOBLIN RAW 700, 450-800Class RC Helicopters, etc. Come on, don't miss this good flying partner!
MAIN FEATURES
➤ High Performance Standard Cyclic Helicopter Servo.
➤ 25T Standard Spline.
➤ High Voltage Capable.
➤ Long Lifespan Brushless Motor.
➤ High Precision Metal Gears.
➤ High Strength Three Ball Bearings.
➤ Full CNC Aluminium Structure.
➤ Suitable for OXY5 MEG, SAB GOBLIN RAW 700, 450-800Class RC Helicopters, etc.
SPECIFICATIONS
Operating Voltage
4.8V- 8.4V
Temperature Range
-15°C - +70°C
Refresh Rate
1520 µS / 333Hz
Travel Angle
180 ± 10°
Programmable
Yes
Case Material
Aluminum
Gear Material
Strength Steel+Titanium
Sensor Type
Potentiometer
Motor Type
Brushless
Bearing
3BB
Direction
CCW
Horn Gear Spline
25T-ɸ5.92 mm
Wire
TYU 300mm / 22AWG
Wire Color
Dimensions
40*20*37.5mm
Weight
79g
Operating Speed
0.060 sec/60° @4.8V
0.050 sec/60° @6.0V
0.042 sec/60° @7.4V
0.038 sec/60° @8.4V
Stall Torque
22 kg·cm (306 oz·in) @4.8V
24 kg·cm (334 oz·in) @6.0V
28 kg·cm (389 oz·in) @7.4V
30 kg·cm (417 oz·in) @8.4V
PACKAGE INCLUDES
➤ 1 x A80BHX-H Servo
➤ 4 x 25T Plastic Horn
➤ 4 x M3*12mm Screw
➤ 1 x M3*8mm Screw
➤ 4 x 9*6.9*5.6mm Rubber Pad
➤ 4 x φ6*φ3.5*5mm Copper Sleeve
➤ 1 x AGFRC Logo Sticker
➤ Perhaps you will need a spec datasheet or other related documents of the products. If there is a download button, it means you can simply click to download. We will continuously update the latest files for each product.
➤ If you do not find the file you want, please feel free to contact shopping@agfrc.com directly.
Spec Datasheet
