HV High Torque Brushless Waterproof 1/5 Servo (A280BHLW)
AGFRC HV MG High Torque Brushless Waterproof 1/5 Servo (A280BHLW)
Ultra-strong torque 100KG 2S A280BHLW 1/5 scale brushless servo the external structure adopts the CNC case design of the cooling groove, It can effectively improve the heat dissipation of the servo during long-time work and prevent the servo from getting hot. The internal structure not only has high-precision reinforced steel gears, but also super silky 5 bearings to closely cooperate with the operation of the servo. Don't forget that it also has an IP67 magnetic waterproof function. Even if it rains, in the snow, by the stream, etc., it can still satisfy your love of the model.
Now our 1/5 servos can be programmed through the AGF-SPV3 programming card, Bluetooth app programming will meet you soon. Hey guys, come on and unlock more model fun!
Main Feature
- 2S 8.4V High Voltage
- IP67 Magnetic Waterproof Function
- Heat Sink Aluminum Case
- Extremely Strong Steel Gears
- Super Reliable Five Ball Bearing
- Associated 15T Aluminum Servo Horns
- High-Efficiency Long-Life Brushless Motor
- It is very suitable for 1/5 scale remote control stunt monster trucks, desert off-road vehicles, crawler, 1/5th drag slash, large size rc planes and Jets.
- Available For Parameter Programmable (Please use with AGFRC USB Programmer AGF-SP V3)
- Bluetooth APP Programmable (Still not available now)
Specification
- Model Name: A280BHLW
- Operating Voltage: 4.8-8.4V
- Operating speed: 0.180 sec/ 60° @ 4.8V
- Operating speed: 0.150 sec/60° @ 6.0V
- Operating speed: 0.125 sec/60° @ 7.4V
- Operating speed: 0.110 sec/60° @ 8.4V
- Stall Torque: 53.0 kg-cm (736 oz-in) @ 4.8V
- Stall Torque: 76.0 kg-cm (1056 oz-in) @ 6.0V
- Stall Torque: 90.0 kg-cm (1251 oz-in) @ 7.4V
- Stall Torque: 100.0 kg-cm (1390 oz-in) @ 8.4V
- Gear: Steel
- Motor: Brushless
- Size: 65.8*30.0*59.0mm(2.59 x 1.18 x 2.32 in)
- Weight: 285g
- Connector Wire: TYU 300mm / 22AWG
Download Spec Datasheet
Please click HERE to download the spec datasheet for the A280BHLW servo.
- Brand:
- AGFRC
- Iterm Name:
- A280BHLW
- Signal Mode:
- Digital
- Control System:
- PWM, 1520uS/333hz
- Dead band:
- 2 uSec
- Operating Voltage:
- 4.8V ~ 8.4V
- Operating Travel:
- 180°±10°
- Signal Range:
- 500 to 2500 uSec
- Angle Sensor:
- Magnet Sensor
- Temperature:
- -15C°~ +70C°
- Mechanical Angle:
- No Limit
- Motor Type:
- Brushless Motor
- Motor Drive:
- FET Drive
- Horn Gear Spline:
- 15T-φ7.8mm
- Programmable:
- Yes
- Waterproof Level:
- IP67
- Bearing:
- Five Ball Bearings
- Bearing Material:
- Metal
- Gear Material:
- Strength Steel
- Case Material:
- AL6061T6
- Certification:
- CE, FCC, RoHs
- Wire Guage:
- TYU 300mm / 22AWG
- Net Weight:
- 283g(9.98oz)
- Product Size:
- 65.8*30.0*59.0mm(2.59*1.18*2.32in)
