AGFRC 8.5kg Programmable High Speed Brushless Metal Gear Middle Digital Tail Servo For Helicopter Glider (A35BHM-H)

It is a helicopter servo with high performance digital circuit, program you own parameter function and 4.8-8.4V wide voltage capable. The unique motor exposed design allows it to be used in more places with the smallest body. At the same time it has a super fast speed of 0.065sec. Keep your eyes open when you use it please, don’t let your beloved airplane disappear from your sight in the blink of your eyes.


Feature

Full CNC Aluminium Shell

Smooth Dual Ball Bearings

Middle Compact Size Design

High Precision Titanium Gear

Longer Lifespan Brushless Motor

2S Lipo Wide Voltage Application

Quick Response and High Accuracy

Available to Be Programmable

Ideal for 380-500 Size Helicopter, 3D helicopters etc.



Stall Torque

  • 5.0 kg-cm (70 oz-in) @ 4.8V

    6.0 kg-cm (83 oz-in) @ 6.0V

    7.5 kg-cm (104 oz-in) @ 7.4V

    8.5 kg-cm (118 oz-in) @ 8.4V


Operating Speed

  • 0.090sec / 60° @ 4.8V
  • 0.080sec / 60° @ 6.0V
  • 0.072sec / 60° @ 7.4V
  • 0.065sec / 60° @ 8.4V


Package Included:

  • Item 1:
  • 1 x A35BHM-H Programmable Brushless Tail Servo
  • 1 x Accessory Kit

  • Item 2:
  • 1 x A35BHM-H Programmable Brushless Tail Servo
  • 1 x 25T Metal Servo Horn
  • 1 x Accessory Kit

  • Item 3:
  • 1 x A35BHM-H Programmable Brushless Tail Servo
  • 1 x AGF-SPV2 Servo Programmer
  • 1 x 25T Metal Servo Horn
  • 1 x Accessory Kit

  • Note: Item 1, 2 does not include the AGF-SPV2 servo programmer.



Brand:
AGFRC
Iterm Name:
A35BHM-H
Signal Mode:
Digital
Control System:
Pulse Width Modulation Control
Refresh Rate:
666Hz
Neutral Position:
760uS
Dead band:
2 uSec
Operating Voltage:
4.8V ~ 8.4V
Operating Temperature:
-15C°~ +70C°
Operating Travel:
180°±10°
Signal Range:
500 to 2500 uSec
Mechanical Limit Angle:
220°
Bearing:
Double Ball Bearing
Angle Sensor:
Potentiometer
Motor Type:
Brushless Motor
Motor Drive:
FET Drive
Programmable:
Yes
Gear Material:
Titanium
Case Material:
AL6061T6
Bearing Material:
Metal
Horn Gear Spline:
25T-φ5.92mm
Wire Guage:
JR 300mm /22AWG
Net Weight:
41g
Product Size:
35.5*15*29.2mm
